// lib/storage-stack.ts
import * as cdk from 'aws-cdk-lib';
import * as s3 from 'aws-cdk-lib/aws-s3';
import { Construct } from 'constructs';

export class StorageStack extends cdk.Stack {
  // 다른 Stack에서 참조할 수 있도록 public으로 노출
  public readonly inputBucket: s3.Bucket;
  public readonly outputBucket: s3.Bucket;
  public readonly modelBucket: s3.Bucket;

  constructor(scope: Construct, id: string, props?: cdk.StackProps) {
    super(scope, id, props);

    // 입력 이미지 버킷: 수명 주기 정책으로 비용 최적화
    this.inputBucket = new s3.Bucket(this, 'InputBucket', {
      bucketName: `vaiaas-input-${this.account}-${this.region}`,
      removalPolicy: cdk.RemovalPolicy.RETAIN,
      lifecycleRules: [
        {
          // 처리 완료된 입력 이미지는 7일 후 자동 삭제
          expiration: cdk.Duration.days(7),
          prefix: 'processed/',
        },
      ],
      cors: [
        {
          allowedMethods: [s3.HttpMethods.PUT, s3.HttpMethods.POST],
          allowedOrigins: ['*'],
          allowedHeaders: ['*'],
        },
      ],
    });

    // 결과 버킷: Intelligent-Tiering으로 비용 최적화
    this.outputBucket = new s3.Bucket(this, 'OutputBucket', {
      bucketName: `vaiaas-output-${this.account}-${this.region}`,
      removalPolicy: cdk.RemovalPolicy.RETAIN,
      intelligentTieringConfigurations: [
        {
          name: 'EntireBucket',
          archiveAccessTierTime: cdk.Duration.days(90),
          deepArchiveAccessTierTime: cdk.Duration.days(180),
        },
      ],
    });

    // 모델 아티팩트 버킷: 버전 관리 활성화
    this.modelBucket = new s3.Bucket(this, 'ModelBucket', {
      bucketName: `vaiaas-models-${this.account}-${this.region}`,
      versioned: true,
      removalPolicy: cdk.RemovalPolicy.RETAIN,
    });
  }
}

// lib/model-stack.ts
import * as cdk from 'aws-cdk-lib';
import * as sagemaker from 'aws-cdk-lib/aws-sagemaker';
import * as iam from 'aws-cdk-lib/aws-iam';
import * as s3 from 'aws-cdk-lib/aws-s3';
import { Construct } from 'constructs';

interface ModelStackProps extends cdk.StackProps {
  modelBucket: s3.Bucket;
  modelVersion: string; // e.g., 'v1.2.0'
}

export class ModelStack extends cdk.Stack {
  public readonly endpointName: string;

  constructor(scope: Construct, id: string, props: ModelStackProps) {
    super(scope, id, props);

    this.endpointName = `vaiaas-endpoint-${props.modelVersion.replace(/\./g, '-')}`;

    // SageMaker 실행 역할
    const sagemakerRole = new iam.Role(this, 'SageMakerRole', {
      assumedBy: new iam.ServicePrincipal('sagemaker.amazonaws.com'),
      managedPolicies: [
        iam.ManagedPolicy.fromAwsManagedPolicyName('AmazonSageMakerFullAccess'),
      ],
    });

    // 모델 버킷 읽기 권한 부여
    props.modelBucket.grantRead(sagemakerRole);

    // SageMaker 모델 정의
    // PyTorch 추론 컨테이너 사용 (AWS Deep Learning Container)
    const model = new sagemaker.CfnModel(this, 'VisionAIModel', {
      modelName: `vaiaas-model-${props.modelVersion.replace(/\./g, '-')}`,
      executionRoleArn: sagemakerRole.roleArn,
      primaryContainer: {
        // AWS 제공 PyTorch 추론 컨테이너
        image: `763104351884.dkr.ecr.${this.region}.amazonaws.com/pytorch-inference:2.1.0-gpu-py310-cu118-ubuntu20.04-sagemaker`,
        modelDataUrl: `s3://${props.modelBucket.bucketName}/models/${props.modelVersion}/model.tar.gz`,
        environment: {
          SAGEMAKER_PROGRAM: 'inference.py',
          SAGEMAKER_SUBMIT_DIRECTORY: '/opt/ml/model/code',
          MODEL_VERSION: props.modelVersion,
        },
      },
    });

    // 엔드포인트 설정: GPU 인스턴스 + 데이터 캡처
    const endpointConfig = new sagemaker.CfnEndpointConfig(this, 'EndpointConfig', {
      endpointConfigName: `vaiaas-config-${props.modelVersion.replace(/\./g, '-')}`,
      productionVariants: [
        {
          variantName: 'AllTraffic',
          modelName: model.modelName!,
          instanceType: 'ml.g4dn.xlarge', // NVIDIA T4 GPU
          initialInstanceCount: 1,
          initialVariantWeight: 1,
        },
      ],
      // 추론 데이터 캡처: 모델 품질 모니터링에 활용
      dataCaptureConfig: {
        enableCapture: true,
        initialSamplingPercentage: 10,
        destinationS3Uri: `s3://${props.modelBucket.bucketName}/data-capture/`,
        captureOptions: [
          { captureMode: 'Input' },
          { captureMode: 'Output' },
        ],
      },
    });

    // 실시간 엔드포인트 배포
    const endpoint = new sagemaker.CfnEndpoint(this, 'Endpoint', {
      endpointName: this.endpointName,
      endpointConfigName: endpointConfig.endpointConfigName!,
    });

    // 오토스케일링 설정 (Application Auto Scaling)
    // 최소 1개, 최대 4개 인스턴스로 트래픽에 따라 자동 조정
    const scalingTarget = new cdk.CfnResource(this, 'ScalingTarget', {
      type: 'AWS::ApplicationAutoScaling::ScalableTarget',
      properties: {
        MaxCapacity: 4,
        MinCapacity: 1,
        ResourceId: `endpoint/${this.endpointName}/variant/AllTraffic`,
        ScalableDimension: 'sagemaker:variant:DesiredInstanceCount',
        ServiceNamespace: 'sagemaker',
        RoleARN: sagemakerRole.roleArn,
      },
    });
    scalingTarget.addDependency(endpoint);

    new cdk.CfnOutput(this, 'EndpointNameOutput', {
      value: this.endpointName,
      exportName: 'VaiaasSageMakerEndpointName',
    });
  }
}

// lib/api-stack.ts
import * as cdk from 'aws-cdk-lib';
import * as apigateway from 'aws-cdk-lib/aws-apigateway';
import * as lambda from 'aws-cdk-lib/aws-lambda';
import * as iam from 'aws-cdk-lib/aws-iam';
import * as s3 from 'aws-cdk-lib/aws-s3';
import { Construct } from 'constructs';

interface ApiStackProps extends cdk.StackProps {
  inputBucket: s3.Bucket;
  outputBucket: s3.Bucket;
  sagemakerEndpointName: string;
}

export class ApiStack extends cdk.Stack {
  constructor(scope: Construct, id: string, props: ApiStackProps) {
    super(scope, id, props);

    // Lambda 공통 레이어 (공통 유틸리티, boto3 최신 버전 등)
    const commonLayer = new lambda.LayerVersion(this, 'CommonLayer', {
      code: lambda.Code.fromAsset('lambda/layers/common'),
      compatibleRuntimes: [lambda.Runtime.PYTHON_3_11],
      description: 'Common utilities and dependencies',
    });

    // 1. Lambda Authorizer: JWT 검증
    const authorizerFn = new lambda.Function(this, 'AuthorizerFunction', {
      runtime: lambda.Runtime.PYTHON_3_11,
      code: lambda.Code.fromAsset('lambda/authorizer'),
      handler: 'index.handler',
      environment: {
        JWT_SECRET_ARN: 'arn:aws:secretsmanager:...',
      },
      timeout: cdk.Duration.seconds(5),
    });

    const authorizer = new apigateway.TokenAuthorizer(this, 'JwtAuthorizer', {
      handler: authorizerFn,
      resultsCacheTtl: cdk.Duration.minutes(5), // 인증 결과 캐싱으로 레이턴시 감소
    });

    // 2. Router Lambda: 요청 라우팅 및 S3 업로드
    const routerFn = new lambda.Function(this, 'RouterFunction', {
      runtime: lambda.Runtime.PYTHON_3_11,
      code: lambda.Code.fromAsset('lambda/router'),
      handler: 'index.handler',
      layers: [commonLayer],
      environment: {
        INPUT_BUCKET: props.inputBucket.bucketName,
        OUTPUT_BUCKET: props.outputBucket.bucketName,
        SAGEMAKER_ENDPOINT: props.sagemakerEndpointName,
      },
      timeout: cdk.Duration.seconds(30),
      memorySize: 512,
      tracing: lambda.Tracing.ACTIVE, // X-Ray 추적 활성화
    });

    // S3 및 SageMaker 권한 부여
    props.inputBucket.grantReadWrite(routerFn);
    props.outputBucket.grantWrite(routerFn);
    routerFn.addToRolePolicy(new iam.PolicyStatement({
      actions: ['sagemaker:InvokeEndpoint'],
      resources: [`arn:aws:sagemaker:${this.region}:${this.account}:endpoint/${props.sagemakerEndpointName}`],
    }));

    // 3. API Gateway 구성
    const api = new apigateway.RestApi(this, 'VaiaaasApi', {
      restApiName: 'VAIaaS API',
      description: 'Vision AI as a Service REST API',
      deployOptions: {
        stageName: 'v1',
        tracingEnabled: true,
        metricsEnabled: true,
        loggingLevel: apigateway.MethodLoggingLevel.INFO,
        // 스로틀링: 초당 100 요청, 버스트 200 요청
        throttlingRateLimit: 100,
        throttlingBurstLimit: 200,
      },
      // CORS 설정
      defaultCorsPreflightOptions: {
        allowOrigins: apigateway.Cors.ALL_ORIGINS,
        allowMethods: ['POST', 'OPTIONS'],
        allowHeaders: ['Content-Type', 'Authorization'],
      },
    });

    // POST /v1/analyze 엔드포인트
    const analyzeResource = api.root.addResource('analyze');
    analyzeResource.addMethod(
      'POST',
      new apigateway.LambdaIntegration(routerFn, {
        timeout: cdk.Duration.seconds(29), // API Gateway 최대 타임아웃은 29초
      }),
      {
        authorizer,
        authorizationType: apigateway.AuthorizationType.CUSTOM,
        // 요청 검증: Content-Type 헤더 필수
        requestValidator: new apigateway.RequestValidator(this, 'RequestValidator', {
          restApi: api,
          validateRequestBody: true,
          validateRequestParameters: true,
        }),
      }
    );

    new cdk.CfnOutput(this, 'ApiUrl', {
      value: api.url,
      description: 'VAIaaS API Gateway URL',
    });
  }
}

# 전체 스택 배포 (처음 배포 시)
cdk bootstrap aws://ACCOUNT_ID/REGION
cdk deploy --all

# 특정 스택만 배포 (모델 업데이트 시)
cdk deploy ModelStack --parameters modelVersion=v1.3.0

# 배포 전 변경 사항 확인
cdk diff ApiStack
